These are V-Belts as only JayDee Enterprises can supply. Please take a moment to review our selection of V-Belts.

If we don't have your belt in stock, we can have it added to our comprehensive inventory -please feel free to call 1-800-989-0162 for assistance.  Inventory highlights include, but are not limited to:

• Banded "B"Section in *Kevlar (Approx. 70 Sizes)
• B-C-D Section in Odd Lengths (Approx. 100 odd sizes)
• Metric Super Torque Timing Belts
• Clutching Dry Fabric Wrapped Belts with Kevlar from 101" to 156" in 1" increments for Outdoor Power Equipment
• AX-BX-CX Cogged Belts over 100 sizes available that are not available from major manufacturers
• Largest Warehouse Stock (Over 175 sizes) of Variable Speed Combine Drive Belts


  For ease in viewing, please note that by clicking on a picture, you will be directed to a catalog
  page with available sizes and pricing for that belt type. If you have questions, or need a full
  catalog, please click here and you will be directed to our full selection (available for download).

(2L-3L-4L-5L) Oil and heat resistant and static dissipating with cotton polyester outer cover. Ideal for any light duty fractional horsepower drives including backside idler applications. FHP V-Belts are measured on the outside diameter (Example 4L400=40"OD).

Fractional Horsepower Dry Fabric Wrapped
V-Belts with
Kevlar* Cord

POLYESTER CORDED

KEVLAR CORDED

(A-B-C-D-E) JayDee Conventional V-Belts are constructed from Kevlar cord. They are oil and heat resistant and static dissipating. Recommended for all general purpose drives with higher horsepower ratings. Conventional V-Belts are measured on the inside diameter (Example A90 = 90"ID - 92"OD).

(3V-5V-8V) Recommended for all heavy duty drives requiring high horsepower and a compact design when space and weight are limiting factors. Oil and heat resistant and static dissipating. Narrow Wedge V-Belts are measured on the outside diameter. (Example 3V500=50"OD).

(AX-BX-CX) Designed for the tough, small sheaves 1+3 high tension drives. Higher horsepower ratings make it possible to use power belts and thus fewer sheave grooves, resulting in lighter, more compact drives, reducing overall drive costs.

(3VX-5VX) Recommended for all drives where compact design is required, higher speed is necessary and increased horsepower required. Heat and oil resistant, static conductive. All sizes are available from stock.

(AA-BB-CC) Double Sided V-Belts are recommended for use in serpentine reverse bend drives or where a change in direction is required. All belts are oil and heat resistant and static dissipating.

(RB-RC-RD) Banded conventional V-Belts are designed for heavy duty drives where shock loading is a problem and multiple matched single belts tend to roll over or jump off.

(SPZ-SPA-SPB-SPC) Metric Narrow Wedge V-Belts are manufactured for high performance. They are highly flexible, oil and heat resistant and static dissipating.

(MXL-XL-L-H-XH-XXH) Recommended for mechanical power transmission drives where synchronization of driven speed to drive speed is required. Possible substitute for chain and gear drives.

(DXL-DL-DH) Recommended for the dual positive drive which is required to change the direction of one or more synchronous pulleys with one belt. The inside and outside teeth are identical in both size and pitch.

Recommended for use on variable speed sheave drives requiring exact speed control and maximum range of speed changes. Arched construction and strong compression section provide great crosswise rigidity that resists distortion. Oil and heat resistant, static conductive.

(J-L-M) Recommended for small sheaves, high speed and/or high ratio drives, having longitudinally ribbed traction surfaces. Oil resistant and static conductive.

(R3VX-R5VX) Banded Narrow Wedge V-belts are designed for heavy duty drives where shock loading is a problem and narrow wedge belts tend to roll over or jump off.

(RBK) Banded Kevlar conventional V-belts are designed as drive belts in heavy duty applications on agricultural equipment such as combines. We maintain a substantial inventory of this type belt.
